Keuffel & Esser, (fl.1867-1982) New York.

K+E Paragon Click Pen, pat. US905419 (1907) invented by Otto Haff. Patent assigned to K+E.
K+E Paragon Click Pen, pat. US905419 (1907) invented by Otto Haff. Patent assigned to K+E.
Esser's patent locking device (K+E catalogue 1909, p.45) pat. US528668 by Adolf Haff. The patent document indicates that Haff assigned the patent rights to K+E.
Esser's patent locking device (K+E catalogue 1909, p.45) pat. US528668 by Adolf Haff. The patent document indicates that Haff assigned the patent rights to K+E.

German immigrants Wilhelm Johann Diedrich Keuffel (*1838-†1908) and Hermann Esser (*1845-†1908) establish scientific instrument manufacturing firm Keuffel & Esser in New York City in 1867. Best known for its popularization of the slide rule, Keuffel & Esser was the first American company to specialize in the manufacture and sale of drafting and surveying tools. By the early twentieth century, it was one of the largest suppliers of scientific instruments in the world.



K+E drawing instrument patents

28 Mar 1893 US494132 Esser's patent pivot joint

06 Nov 1894 US528668 Esser's patent locking device

15 Oct 1901 US684437 Drawing pen with lever [6]

19 Feb 1907 US844772 Straightening device

01 Dec 1908 US905419 Click pen

08 Jul 1924 US1500246 Straightening device

19 May 1936 US2041299 Bifurcated drawing instrument

Fig.1. and 2. K+E Lithographic compass set.

Fig.3. and 4. Key Instruments proportional dividers by Keuffel & Esser. Key Instruments (drawing instruments and sets) was a brand marketed by Keuffel & Esser. These proportional dividers, graduated for lines and circles, feature a micrometer bar for accurately setting divisions for line or circle. The bar can also be moved in a position to accurately set the distance betrween the points. Dividers measure 245mm in length.

___________________

NOTES / REFERENCES

[1] Hoboken Historical Museum: Online Collections Database;  Partners in Creating. The First Century of K+E 1867/1967

[2] Landmarks Preservation Commission KEUFFEL & ESSER COMPANY BUILDING, 127 Fulton Street

[3] K+E Timeline

[4] Wilhelm J.D. Keuffel (1838-1908)

[5] Keuffel & Esser published a monthly journal called The Compass. Issues for the years 1891-1892 are available on google books. New York Public Library holdings run from 1891 to 1894.

[6] Also see similar lever pens by Theo Alteneder US568556A and the 'Hebel-Feder' by E.O. Richter (1928 cat p.44.)


K+E ONLINE CATALOGUES

  Year   Edition   Source   Notes
  1883   17th edition   HathiTrust
  1890   21st edition    Internet Archive
  1892   23rd Edition, 1892   Hoboken Historical Museum
  1900   30th edition, 1900   Antique Surveying Instruments
  1904   Instruments for Forest Work   Internet Archive   instruments for forest work
  1909   33rd edition   Carnegie Library of Pittsburgh
  1913   34th edition   Internet Archive
  1921   36th edition    HathiTrust
  1925   K+E Drawing Instruments   Internet Archive
  1936   38th edition   Internet Archive
  1949   41st edition   Internet Archive  drafting & reproduction catalog
  1963   K+E Educational Supplies & Equipment   Internet Archive
